You are here : Home → PRODUCTS → Horizontal Measuring Instruments(LAB)

Dantsin-Trimos TELS

Spec:

TECHNICAL SPECIFICATIONSTELSAbsolute measuring rangemm (in)25 (1)Application range (external measurements)mm (in)100 (4)Application range (internal measurements)mm (in)100 (4)Resolutionsmm (in)0.1 ÷ 0.0001 (.001 ÷ 00001)Measuring force (adjustable)N3-8Operational temperature°C+10 ÷ +40Temperature of storage°C-10 ÷ +40Weightkg15

Scope:

Availability: 2021 - 03 - 22

Describe:

Explain:

The Mini-Horizontal TELS is the ideal instrument for checking small dimensions. It is part of the horizontal instruments family.The instrument is mainly used for checking internal and external dimensions, such as ring gauges, plug gauges, thread plug gauges and for measuring precision production parts.The reliable concept is easily suitable for the use in workshop environment. An electronic probe and digital display unit or simply a dial indicator can be applied to perform all measurements. The selection of the measuring system depends on the required accuracy.The range for internal measurements from 10 to 100 mm and external measurements from 0 to 100 mm covers a large number of applications. The absolute measuring range is 25 mm and a preset setting is necessary to obtain an entire lengt...

Catalog Download

Inquiry

Description
Technical
cification
Video
Success Case
Related Products

The Mini-Horizontal TELS is the ideal instrument for checking small dimensions. It is part of the horizontal instruments family.

The instrument is mainly used for checking internal and external dimensions, such as ring gauges, plug gauges, thread plug gauges and for measuring precision production parts.

The reliable concept is easily suitable for the use in workshop environment. An electronic probe and digital display unit or simply a dial indicator can be applied to perform all measurements. The selection of the measuring system depends on the required accuracy.

The range for internal measurements from 10 to 100 mm and external measurements from 0 to 100 mm covers a large number of applications. The absolute measuring range is 25 mm and a preset setting is necessary to obtain an entire length. A wide range of accessories are available.

Ideal for checking small dimensions
Easy manipulation
Suitable for use in workshop area
Wide range of accessories


TECHNICAL SPECIFICATIONS

TELS
Absolute measuring range	mm (in)	25 (1)
Application range (external measurements)	mm (in)	100 (4)
Application range (internal measurements)	mm (in)	100 (4)
Resolutions	mm (in)	0.1 ÷ 0.0001 (.001 ÷ 00001)
Measuring force (adjustable)	N	3-8
Operational temperature	°C	+10 ÷ +40
Temperature of storage	°C	-10 ÷ +40
Weight	kg	15
